Elevate the performance and user experience of your intelligent equipment with our premium AG etched + AF anti-fingerprint cover glass. Engineered specifically for high-touch, high-visibility environments, this advanced composite cover glass combines permanent chemical etching for superior anti-glare performance with a durable oleophobic AF nano-coating that repels fingerprints, oils, and smudges.
Ideal for industrial HMIs, medical panels, outdoor kiosks, smart home controllers, automotive displays, self-service terminals, and other intelligent devices, our AG+AF cover glass delivers crystal-clear readability under bright lighting while keeping surfaces cleaner longer and easier to maintain.
Micro-etched surface creates controlled haze (typically adjustable 5–25%) that diffuses ambient light and eliminates harsh reflections. Permanent etching will not peel, wear off, or degrade like sprayed coatings—ensuring lifelong anti-glare reliability even in outdoor or high-ambient-light conditions.
Nano-scale fluoropolymer layer achieves water contact angles ≥110° (premium grades ≥115°). Fingerprints and oils bead up and wipe away effortlessly with a single pass. Reduces cleaning frequency by up to 70% and keeps displays looking pristine in high-traffic applications.
High light transmittance (typically ≥89–92%) with balanced haze that preserves image sharpness and color accuracy. Optional low-sparkle formulations available for high-resolution displays.
Compatible with chemical strengthening for enhanced impact and scratch resistance (pencil hardness up to 7–9H depending on substrate). Smooth, silky touch feel improves finger glide and capacitive touch accuracy. Excellent chemical and environmental resistance for demanding industrial and outdoor use.
Material | Soda-lime,Aluminosilicate, Gorilla Glass |
Thickness | 0.28mm – 12mm |
Size | 1″ – 100″+ |
Shape | 2D,2.5D,3D finishing, custom cut-outs |
AG Haze Level | 3% –15% adjustable |
Edge Finish | Rounded, beveled, polished |
Printing | Silk-screen,digitalprinting,logo branding |
Color | Black bezel,custom ink colors |
Additional Coatings | AR(Anti-Reflective) available upon request |
Bonding | Optical bonding for enhanced durability |
l Industrial HMI and PLC control panels
l Medical and laboratory touch displays
l Outdoor and semi-outdoor kiosks, ATMs, EV chargers, and digital signage
l Smart home wall controllers, thermostats, and appliance interfaces
l Automotive center displays and instrument clusters
l Self-service terminals, POS systems, and access control devices
l Other intelligent equipment requiring reliable touch interaction under varied lighting and high-use conditions
Information | What to Provide |
Drawing | Overall size, thickness, shape, holes, cutouts and edge profile |
Glass Material | Soda-lime, aluminosilicate or named material grade |
Display Information | LCD/OLED model, resolution / pixel density, viewing distance and bonding structure |
AG Requirement | Haze, gloss, Ra, sparkle / clarity target or approved comparison sample |
AF Requirement | Water contact angle, abrasion durability, cleaning chemicals or touch-feel requirement |
Strengthening | Chemical strengthening / thermal tempering requirement and mechanical test targets |
Printing | Black mask, logo, icon, color and tolerance requirements |
Bonding | OCA/OCR/LOCA or other adhesive / module assembly requirement |
Volume | Prototype quantity and expected mass-production volume |
Unlike simple coatings that can wear off, our chemical-etched AG provides permanent glare control, while the top AF layer ensures easy cleaning and a premium tactile feel. The AG+AF combination is the industry-preferred solution for intelligent equipment that must remain readable, hygienic, and professional-looking day after day.
Fuxin Glass offer full OEM/ODM support—from prototype sampling to high-volume production—with strict quality control, consistent batch-to-batch performance, and flexible customization to match your exact optical, mechanical, and aesthetic requirements.
Contact us now for samples, technical data sheets, or a customized quotation. Optimize your intelligent equipment’s display performance with high-performance AG etched & AF anti-fingerprint cover glass engineered for real-world reliability.
2A means two surface functions are combined on one cover glass: AG anti-glare and AF anti-fingerprint. AG controls glare, while AF improves cleanability and touch feel.
Chemical etching forms the anti-glare texture directly in the glass surface, so the AG texture itself is not a separate deposited matte film. Final durability still depends on the complete glass process, strengthening, handling and any additional coatings.
AG introduces controlled light scattering, so there is always a trade-off between glare reduction and fine-detail clarity. For high-resolution displays, haze, gloss, sparkle and viewing conditions should be validated together on the actual display module.
No. AF coating reduces fingerprint and oil adhesion and makes the surface easier to wipe clean, but fingerprints can still appear depending on use, contamination and coating wear.
Yes, some projects can use an AG+AR+AF 3A configuration when the substrate, coating sequence and optical targets are compatible. The final stack should be confirmed by sample and testing.
Yes. FUXIN supports custom dimensions, thicknesses, holes, cutouts, edge profiles, strengthening, black borders, logos, icons and other drawing-based OEM requirements.
Yes. Samples can be used to verify optical appearance, glare, fingerprint behavior, touch feel, dimensional fit, printing and bonding compatibility before volume production.
