FUXIN custom AG anti-glare cover glass is engineered for high-resolution touch displays, pen displays and drawing tablets where glare control must be balanced with image sharpness. A chemically etched micro-texture creates controlled surface diffusion, helping reduce mirror-like reflections from ambient lighting while maintaining the detail, contrast and color performance required by 4K and 8K screens.

The AG surface can be specified within an Ra range of 0.08–0.40 μm according to the application's target glare reduction, visual clarity and tactile feel. FUXIN supports custom dimensions, thicknesses, cutouts, edge profiles, strengthening, silk-screen printing and optional AF or AR combinations from prototype evaluation through volume production.

For OEM projects, send your drawing, glass thickness, display type, target AG performance and required coating combination. Our team can recommend a suitable substrate and surface specification for sampling and production.

Key Features

l  Customizable Dimensions: Available in a wide range of sizes and thicknesses to fit your exact panel or tablet design.

l  Optimized AG Surface (Ra 0.08–0.40 µm): Fine-tuned micro-texture that scatters ambient light effectively while maintaining high transmittance and low haze for sharp 4K/8K imagery.

l  Superior Anti-Glare Performance: Minimizes reflections and glare under office, studio, or outdoor lighting without sacrificing color accuracy or contrast.

l  High Optical Clarity: Excellent light transmission and low distortion support vibrant, true-to-life visuals on ultra-high-resolution screens.

l  Precise Touch &Stylus Response: Smooth surface feel ideal for finger touch and pressure-sensitive styluses used in digital art and design work.

l  Durable & Easy to Integrate: Compatible with standard lamination, optical bonding, and touch sensor processes.

Technical Specifications

Target Applications

l  High-Resolution Touch Panels (4K/8K): Preserves pixel-perfect clarity while eliminating ambient reflections—ideal for premium commercial displays, interactive kiosks, and digital signage.

l  Drawing Tablets & Pen Displays: The Ra 0.08–0.40μm surface provides the perfect paper-like texture for stylus control, reducing finger slipping and sticky drag. Combined with optional AF coating, it resists skin oils for easy maintenance.

l  Industrial HMIs & Control Panels: Durable, scratch-resistant surface ensures reliable readability under bright factory lighting.

l  Medical Displays: Precision optical performance with anti-glare protection for diagnostic monitors and medical interfaces.

l  Outdoor & Window-Facing Displays: Reduces glare from direct sunlight and ambient light—perfect for retail windows, outdoor kiosks, and public terminals.

l  Automotive Infotainment: Scratch-resistant, glare-free surface for dashboard displays and navigation screens.

Customization Options from Fuxin Glass

We offer comprehensive OEM/ODM customization to meet your exact project requirements:

AG vs. AR vs. AF: Which Surface Treatment Does Your Display Need?

AG anti-glare treatment reduces visible reflections by diffusing incident light through a micro-textured surface. It is especially useful where ambient reflections are distracting and a matte viewing surface is acceptable.

AR anti-reflective treatment uses optical coating layers to reduce reflection while retaining a smoother, clearer surface. It is commonly selected when maximum clarity and low reflection are more important than a matte tactile surface.

AF anti-fingerprint treatment improves cleanability and reduces fingerprint adhesion. It does not replace AG or AR, but can be combined with them in suitable process stacks.

For projects that require multiple functions, FUXIN can evaluate AG+AF, AG+AR or 3A AG+AR+AF configurations according to the substrate, optical targets and end-use environment.

Why Choose This AG Cover Glass?

Unlike standard clear glass that produces harsh reflections or overly aggressive AG treatments that blur fine detail, our controlled Ra range strikes the perfect balance. Designers and engineers get the anti-glare benefits they need while preserving the sharpness and color fidelity demanded by 4K/8K content and high-precision drawing work. Custom sizing means you receive glass that fits your design without costly post-processing or yield loss.

Ordering & Customization: Tell us your required dimensions, thickness, edge treatment, and any additional coatings (AR, AF, oleophobic, etc.). We support both prototype and volume production.

FAQs

Q: What does the Ra 0.08–0.40 µm range mean for the AG surface?

It indicates a precisely controlled surface roughness that provides effective anti-glare performance while maintaining high clarity and low haze, ideal for sharp 4K/8K visuals.

Q: Can the glass be customized to any size?

Yes.We offer fully customizable dimensions, thickness, and edge treatments to match your specific touch panel or drawing tablet requirements.

Q: Is this AG glass suitable for both finger touch and stylus input?

Yes.The smooth, controlled AG surface delivers accurate response for capacitive touch and pressure-sensitive styluses used in digital drawing.

Q: Does the anti-glare treatment reduce image clarity or color accuracy?

No.Our optimized Ra range effectively scatters reflections without significantly affecting transmittance, contrast, or color fidelity on high-resolution displays.

Q: Do you provide samples or technical support for custom orders?

Yes. Samples and detailed technical drawings are available upon request.Our team can also assist with optical bonding, coatings, and volume production needs.
